AC-621-35
AC-621-35 - Hanging Support for 35mm Tube Truss
The AC-621-35 support is designed for securely hanging 35mm tube trusses. Featuring an M-10 ring, this support has a load capacity of up to 200 kg, making it ideal for applications requiring reliable support for lightweight and medium trusses. The AC-621-35 is also available in black (ref. AC-621-35B). With a lightweight design of only 0.90 kg, it is easy to handle and position in various mounting configurations. Specifications:- Name: AC-621-35
- Description: Hanging support for 35mm tube truss
- Ring: M-10
- Max load: 200 kg
- Weight: 0.90 kg
- Available in black: ref. AC-621-35B
Technical specifications
Details
Technical specifications
-Main tube: 20 x 2mm
-Secondary tube: 6mm
-Alloy: EN-AW 6082 T6
-Material: Steel
-Connection system: Conical
Details
