SQ-10
SQ-10 - 10x10cm Square Truss
The SQ-10 is a 10x10cm square truss, ideal for small constructions and modular systems. It includes connectors for easy installation and is available in silver and black colors. The available lengths range from 0.5m to 3m, offering flexibility for various applications. Specifications:- Product Name: SQ-10
- Description: 10 x 10 cm square truss. Connectors included.
- Available Colors: Silver, Black
- Available Lengths: 0.5m, 1m, 1.5m, 2m, 2.5m, 3m
- Material: Aluminum EN AW-6061 T6
- Main Pipe Diameter: 20 mm
- Main Pipe Wall Thickness: 2 mm
- Brace Diameter: 6 mm
| Main tube | 20 x 2mm |
| Secondary tube | 6mm |
| Alloy | EN-AW 6082 T6 |
| Available lengths | 0,5m, 1m, 1,5m, 2m, 2,5m and 3m |
| Connection system | Conical |
Technical specifications
Details
Technical specifications
-Maximum height: 9,3m
-Maximum load: 600kg
-Main tube: 50 x 3mm
-Secondary tube: 20 x 2mm
-Truss type: SQR-29
-Alloy: EN-AW 6082 T6
-Workspace: 2,60 x 3,20m
-Connection system: Conical
-Maximum wind speed: 70km/h
Details
