Maximum height: 6,40m
Height folded: 1,92m
Maximum load: 200kg
Minimum charge: 25kg
Material: Galvanized steel under EN 10305-5.
Workspace: 1,44 x 1,44m
Closed base area: 0,47 x 0,47m
Winch: AL-KO 501 Plus 500kg
Cable: Galvanized steel under EN 12385-4.
Maximum cable load: 2.150kg
Cable twisting resistance : 1.770N/mm²
Cable diameter: 6mm
Cable composition: 7x19+0
Security system: External trigger in sections
Leg attachment: Safety pins
Bubble level: to vertically adjust the tower.
Leg base safety lock: The automatic leg locking system allows the outriggers to anchor easily in the correct place, doing away with old and uncomfortable safety pin rings.
Polyamide plates: This raw material offers more resistance than metal and it is wear free. The Polyamide plates can rest against any surface without damaging it, carpet, tiles, etc.
Safety pins: Safety pins stop the load from falling down. You can select different tower heights safely by raising the bars equally, this distributes the load evenly from the main bar to the last bar. Ultimately this prolongs the towers lifetime and increases its stability.
Winch: Our winches are manufactured by industry leading companies. They are resistant and durable as well as oversized for additional safety and better cable pull.
Reinforced base: All our towers use a reinforced iron base that supports heavy loads and high heights.
Circular bubble level: The location of the level at the base helps you stabilise the tower easily and accurately.
Pulleys and pulley-holders: They are made of reinforced steel.
